AHRS-FY2000B Inertial Navigation For Position Measure System

FOB Reference Price:Get Latest Price
US $80-90 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
feiyu-tech
Model Number:
FY-2000B
function::
measure vehicle orientation
materail::
Aluminum
stype::
Radio control toy
level::
high-precision positioning
appication::
ground transportation, robots, aircrafts, video camera etc
weight::
18g
size::
45mm*25mm*11mm
input vlotage::
3.3-6V
Supply Ability
Supply Ability:
500 Set/Sets per Week
Packaging & Delivery
Packaging Details
26*20*87cm
Port
shenzhen
Lead Time :
1day

Specifications

1.small size and light weight
2. auto-calibrate
3. Super long time stability and fast dynamic response

AHRS-FY2000B Inertial Navigation For Position Measure System




we are the company design,develop ,and produce the flight control system for UAV or FPV
we have all kinds of radio controllers and the aircrafts
we can offer you the best quality and the best technical support and the best service



product introduction:



FY-AHRS-2000B is a high-performance strap down inertial navigation system that can measure any point of orientation of the entire locomotive and vehicle in the 3D space. AHRS could make high-precision positioning for any stationary or moving objects with angular velocity, even short magnetic interference will not affect the heading accuracy of the AHRS. The system can be carried out AHRS magnetic field calibration, to eliminate the hard and soft iron materials motorcycles offset caused by magnetic fields.





Features:



1Using high-performance all solid-state three-axis accelerometer, three-axis angular rate sensors and three-axis magnetic field sensor.



2Three axis 360-degree all-dimensional output of the attitude and heading, attitude and heading data on a static accuracy of less than 0.5 degrees, the dynamic accuracy of less than 2 degrees.



3Built-in sensor auto-calibrate, can automatically compensate for the interference of temperature drift, noise, external magnetic field, etc.



4Super long time stability and fast dynamic response.







    The AHRS includes three gyroscopes, three accelerometers and three magnetic field meters. Real-time measure three axial angular velocity, acceleration, and magnetic field strength. After the processing by the internal microprocessor, the AHRS outputs drift-free attitude and heading information, the three-dimensional acceleration, three-dimensional angular velocity, three-dimensional geomagnetic field, which have been compared and checked-off.














Set Content:



1. FY-AHRS-2000B module



2. USB Cable



3. Software CD
